| Parameters | Unit | Value |
| Center Wavelength | nm | 1310 or 1550 |
| Operating Wavelength Width | nm | ±15 |
| Max.Insertion Loss | dB | 0.6 |
| Faraday Rotation Angle for CWL | deg | 45 |
| Max.Rotation Angle Tolerance at 23 ℃ for CWL | deg | ±3 |
| Min.Extinction Ratio | dB | 20 |
| Max.PMD | ps | 0.05 |
| Power Handling | mW | 500 |
| Fiber Type | – | PM Panda fiber |
| Max.Tensile Load | N | 5 |
| Operating Temperature | ℃ | -5~+70 |
| Storage Temperature | ℃ | -40~+85 |
| For device with connector, IL is 0.3dB higher, RL is 5dB lower; |
| 1 | Center wavelength: | 1550=1550nm,1310=1310nm,……,0850=850nm |
| 2 | Fiber type for output: | 1=PM Panda fiber |
| 3 | Pigtail type: | 0=250 bare fiber, 1=900um loose tube, 2=2.0mm loose tube, 3=3.0 loose tube |
| 4 | Fiber length: | 0=0.8m,1=1m |
| 5 | Connector type: | 0=FC/UPC,1=FC/APC,2=SC/UPC,3=SC/APC,4=LC/UPC,5=LC/APC |
| Parameters | Unit | Value |
| CenterWavelength | nm | 1310or1550 |
| OperatingWavelengthWidth | nm | ±15 |
| Max.InsertionLoss | dB | 0.6 |
| FaradayRotationAngleforCWL | deg | 45 |
| Max.RotationAngleToleranceat23℃forCWL | deg | ±3 |
| Min.ExtinctionRatio | dB | 20 |
| Max.PMD | ps | 0.05 |
| PowerHandling | mW | 500 |
| FiberType | – | PMPandafiber |
| Max.TensileLoad | N | 5 |
| OperatingTemperature | ℃ | -5~+70 |
| StorageTemperature | ℃ | -40~+85 |
| Fordevicewithconnector,ILis0.3dBhigher,RLis5dBlower; |
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！ Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. rther details are available from any Andxe System sales representative.
