1×2 1064nm 10W 20W PM Filter Coupler

1×2 1064nm High Power PM Filter Coupler

Features

Applications

Low Insertion Loss

EDFA & Raman Amplifier

High Return Loss

Fiber Sensor

High Extinction Ratio

Fiber Optical Instrument

Specifications

Parameter

Unit

Value

Type

–

1×2

Center Wavelength

nm

1064

Operating Wavelength Range

nm

±20

Max. Excess Loss

dB

0.8

Uniformity (only for 50/50)

dB

0.5

Coupling Ratio

dB

01/99~50/50

Min. Extinction Ratio at 23℃

Both axis working

dB

20

Fast axis blocked

dB

18

Min. Return Loss

dB

50

Max. Optical Power(CW)

mW

10, 20 or Specify

Max.Tensile Load

N

5

Fiber Type

Tap Port

–

PM Panda Fiber or SM Fiber

Input & Output Port

–

PM Panda Fiber

Operating Temperature

℃

-5~+70

Storage Temperature

℃

-40~+85

*Above specifications are for device without connector.

*For device with connector, IL is 0.3dB higher, FTL is 5dB lower, and ER is 2dB lower.

*The default connector key is aligned to slow axis.

Ordering Information

PMFC-1111-2334-555-666–78-9-AABB

1111 – Wavelength:

1064=1064nm, SSSS=Specify

2 – Configuration:

3=1×2

33 – Tap ratio:

01=1%, 02=2%, 05=5%,……, 50=50%

4 – Working Axis:

B=Both axis working, F=Fast axis blocked

555 – Fiber type for Port 1, 3:

003=PM980, 015=PM1060L, 018=PLMA-GDF-10/125-M, SSS=Specify

666 – Fiber type for Tap:

003=PM980, 015=PM1060L, 018=PLMA-GDF-10/125-M. SSS=Specify

7 – Package Dimension:

1=70x12x8mm, S=Specify

8 – Pigtail Type:

0=bare fiber, 1=900μm loose tube

9 – Fiber Length:

0.75=0.75m, 1.0=1m, S=Specify

AA – Average Power:

10=10W, 20=20W, 30=30W, SS=Specify

BB – Peak Power:

00=Continuous Wave, 10=10kW, SS=Specify
