Features |
Applications |
|||
|
High Power Handling |
Coherent Communication |
|||
|
Low Insertion Loss |
Power Monitor |
|||
|
High Stability & Reliability |
Fiber Sensor |
|||
|
|
|
|||
|
Specifications |
||||
|
Parameter |
Unit |
Value |
||
|
Center Wavelength |
nm |
1550 |
||
|
Operating Bandwidth |
nm |
±20 |
||
|
Max. Excess Loss |
dB |
1.0 (Typ.0.8) |
||
|
Min. Extinction Ratio |
dB |
18 |
||
|
Splitting Ratio Tolerance (33:33:33) |
% |
±10 |
||
|
Min. Directivity |
dB |
50 |
||
|
Max. Return Loss |
dB |
50 |
||
|
Max. Optical Power(CW) |
W |
2 |
||
|
Fiber Type |
– |
PM 1550 fiber |
||
|
Package Dimension |
mm |
Φ4*70 |
||
|
Operating Temperature |
℃ |
–20~+70 |
||
|
Storage Temperature |
℃ |
-40~+85 |
||
|
Storage Temperature |
℃ |
-40~+85 |
||
|
*Above specifications are for device without connector. *For device with connector, IL is 0.3dB higher, FTL is 5dB lower, and ER is 2dB lower. *The default connector key is aligned to slow axis.
|
||||
|
Ordering Information |
||||
|
PMFUC-1111-2344-555-67-8-999 |
||||
|
1111 – Wavelength: |
1550=1550nm |
|||
|
2 – Grade： |
P=Grade P |
|||
|
3 – Port Type: |
4=1x3 |
|||
|
44 – Tap Ratio： |
33=33:33:33 |
|||
|
555 – Fiber type： |
001=PM1550, SSS=Specify |
|||
|
6 – Package Dimension: |
2=φ4.0x70mm, S=Specify |
|||
|
7 – Pigtail type: |
0=bare fiber, 1=900μm loose tube |
|||
|
8 – Fiber length: |
0.75=0.75m, 1.0=1m, S=Specify |
|||
|
9999 – Connector type: |
0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specify |
|||
工作温度：商业级/工业级/军品级可选
