产品描述
QSFP+ Passive Direct Attach Copper Cable assemblies were developed for high-density applications, offering a costeffective, low-power option for high-speed data center interconnects. The QSFP+ form factor can replace up to four standard SFP+ connections, providing greater density and reduced system cost. The direct-attach assemblies support emerging 40Gb/s applications and are available in standard lengths up to 10 meters with longer custom lengths available
工作温度：商业级/工业级/军品级可选
技术参数
| 参数 | 指标 |
| 封装 | QSFP+ to QSFP+ |
| 传输速率 | 40G |
| 波长 | N/A |
| 光器件 | N/A |
| 发光范围 | N/A |
| 收端灵敏度 | N/A |
| 接口 | QSFP+ |
| 工作温度范围 | 商业级/工业级/军品级可选 |
| 传输距离 | 0.5~10m |
| 多速率兼容 | Y |
| 中国事业部 |
应用范围
- 40G Ethernet
- Infiniband 4X SDR DDR QDR
- Serial data transmission
