450nm Polarization Maintaining Isolator |
||||
|
|
|
|||
|
Features |
Applications |
|||
|
Low Insertion Loss |
Testing Instrument |
|||
|
High Return Loss |
Raman Fiber Laser |
|||
|
High Isolation |
Ultra-fast Fiber Laser |
|||
|
High stability & Reliability |
|
|||
|
|
|
|||
|
Specifications |
||||
|
Parameters |
Unit |
Value |
||
|
Center Wavelength |
nm |
450 |
||
|
Operating Wavelength Range |
nm |
±5 |
||
|
Min. Isolation at 23℃ |
dB |
22 |
||
|
Typ. Insertion Loss at 23℃ |
dB |
1.7 |
||
|
Max. Insertion Loss at 23℃ |
dB |
2.0 |
||
|
Min. Extinction Ratio at 23℃ |
dB |
18 |
||
|
Min. Return Loss at 23℃ (Input /Output) |
dB |
45 |
||
|
Max. Optical Power (CW) |
mW |
300 |
||
|
Max. Tensile Load |
N |
5 |
||
|
Package Dimension |
mm |
44x28x26 |
||
|
Operating Temperature |
℃ |
+10~+50 |
||
|
Storage Temperature |
℃ |
0~+60 |
||
|
*Above specifications are for device without connector. |
||||
|
*With connector, the handling power is 50mW, IL is 1.0dB higher, FTL is 5dB lower, and ER is 2dB lower. |
||||
|
*The default connector key is aligned to slow axis.
|
||||
|
Ordering Information |
||||
|
HPMIS-①①①–②–③③③-④⑤-⑥-⑦⑦-⑧⑧⑨⑨ |
||||
|
①①① |
– Center Wavelength: |
450=450nm, 532=532nm, SSS=Specified |
||
|
② |
– Working Axis: |
F=Fast axis blocked |
||
|
③③③ |
– Fiber Type: |
105=PM460-HP, SSS=Specified |
||
|
④ |
– Pigtail Type: |
0=250μm bare fiber, 1=900μm loose tube |
||
|
⑤ |
– Package Dimensions: |
0=44x28x26mm |
||
|
⑥ |
– Fiber Length: |
0.8=0.8m, 1.0=1m, S=Specified |
||
|
⑦⑦ |
– Connector Type: |
0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, 4=LC/UPC, 5=LC/APC, N=None |
||
|
⑧⑧ |
– Average Power: |
00=100mW |
||
|
⑨⑨ |
– Peak Power: |
00=Continuous Wave, SS=Specified |
||
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
