※如果您需要定制服务，例如更多输出端口或该模块的一些特殊输入/输出功率值，请发送电子邮件至 sales@fibre-mart.com，我们将在 24 小时内与您联系。 光学特性
(1)：输出功率和双路输出可选。 (2)：0dBm输入测试 电气特性
※实际功耗取决于输出功率和环境温度。 环境特点
| Category | Structure | Application | Input Power | Output Power | Output port | Voltage | Interface |
| M: Module |
10: Mechanical Dimension: 150×125×19mm |
2: Fiber Amplifier |
1: -3~10dBm 9: other |
13: 13dBm … 24: 24dBm |
1: 1port
2: 2ports |
7: 5V DC 8: 3.3V DC |
1: SC/UPC 2: SC/APC 3: FC/UPC 4: FC/APC 5: LC/UPC 6: LC/APC |
| Parameter | Symbol | Min | Typ | Max | Unit |
| Wavelength | λc | 1530 | 1550 | 1562 | nm |
| Output power (1) | Po | —— | 23 | dBm | |
| Input power | Pi | -3 | —— | 10 | dBm |
| Gain | G | —— | —— | dB | |
| Noise Figure (2) | NF | —— | 4.5 | —– | dB |
| Output power stability | ΔPo | —– | ±0.05 | ±0.1 | dB |
| Return Loss | RL | ——- | ——- | -45 | dB |
| PDG | PDG | —— | ——- | 0.3 | dB |
| PMD | PMD | —— | ——- | 0.5 | ps |
| Parameter | Symbol | Min | Typ | Max | Unit |
| Power Supply | Vps | 3.0/4.5 | 3.3/5.0 | 3.3/5.0 | VDC |
| Consumption※ | P | —– | —- | 20 | W |
| Parameter | Symbol | Min | Typ | Max | Unit |
| Operating temperature | Tw | -5 | —– | 60 | ℃ |
| Storage temperature | Ts | -40 | —– | 80 | ℃ |
| Humidity | —— | 10 | —— | 85 | % |
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！ Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. rther details are available from any Andxe System sales representative.
