FT-E130T是Fiber-MART公司自主研发的FTTX电信级小型局端OLT设备； 符合IEEE802.3-2005标准； 可为用户提供宽带、语音、IPTV、CATV等综合业务的接入。
我们的EPON系统最多支持256个逻辑链路标识符（LLID）； 支持动态带宽分配（DBA）和上下行流量限速、最小和最大带宽控制以及不同的流加权系数，充分保证QOS。
我们的FM-E130T OLT支持自动发现、自动识别和自动注册、用户线路测试、远程ONU光纤故障和断电警报。 它还支持灵活可控的组播，支持IGMP Snooping。
注：本设备不带PON模块和上行模块。
| Parameters | Specifications |
| Wavelength (nm) | 1310(RX)/1490(TX) |
| Transmission Distance (km) | 20 |
| MAC Address Table | 4K MAC address list (Uplink port supports electronic port modules and optical port modules, which can be configured flexibly as required) |
| MTBF (hrs) | 100,000 |
| Product Features |
1. 1U case,Good shielding measures 2. Layer 2 aggregation switching 3. Layer 2 wire-speed forwarding 4. support rich layer 2 protocols |
| Protocols |
1. IP ToS 2. IEEE802.1p priority |
| Network Management |
1. Support in-band management, out-of-band management 2. Support online upgrade of device software |
| Port features |
1. 1 PON ports (1.25G) 2. 1 uplink ports (1G) (electronic ports and optical ports options) 3. 1 management ports (special software management) 4. 1 console port |
| Power Consumption | DC (5V/4A) (20W) |
| Operating Temp. (°C) | 0℃~+45℃ |
| Storage Temp. (°C) | -30℃~+60℃ |
| Storage Humidity | 10℃~+90℃ ;non-condensing |
| Rack Dimensions (mm) | 440(L) x 207(W) x 43.6(H) |
| Parameters | Specifications |
| Wavelength (nm) | 1310(RX)/1490(TX) |
| Transmission Distance (km) | 20 |
| MAC Address Table | 4K MAC address list (Uplink port supports electronic port modules and optical port modules, which can be configured flexibly as required) |
| MTBF (hrs) | 100,000 |
| Product Features |
1. 1U case,Good shielding measures 2. Layer 2 aggregation switching 3. Layer 2 wire-speed forwarding 4. support rich layer 2 protocols |
| Protocols |
1. IP ToS 2. IEEE802.1p priority |
| Network Management |
1. Support in-band management, out-of-band management 2. Support online upgrade of device software |
| Port features |
1. 1 PON ports (1.25G) 2. 1 uplink ports (1G) (electronic ports and optical ports options) 3. 1 management ports (special software management) 4. 1 console port |
| Power Consumption | DC (5V/4A) (20W) |
| Operating Temp. (°C) | 0℃~+45℃ |
| Storage Temp. (°C) | -30℃~+60℃ |
| Storage Humidity | 10℃~+90℃ ;non-condensing |
| Rack Dimensions (mm) | 440(L) x 207(W) x 43.6(H) |
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！ Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. rther details are available from any Andxe System sales representative.
