QSFP28-50G-LR 50G QSFP28 LR 1310nm 10km PAM4 LC SMF DDM Transceiver Module

QSFP28-50G-LR — F-tone 50G QSFP28 LR transceiver Module uses the wave length of 1310nm and supports up to 10km link lengths over SMF via a Duplex LC connector.

产品详情

产品参数 — F-tone
F-tone型号	QSFP28-50G-LR	制造商名称	F-tone
封装	QSFP28	传输速率	50Gbps
波长	1310nm	最远传输距离	10km
接口类型	双工 LC	发射激光器类型	DML
线缆类型	单模(SMF)	光接收器件类型	PIN
发射光功率	-4.5~+4.2dBm	接收灵敏度	< -8.4dBm
协议	MSA Compliant, SFF-8665 and SFF-8679	工作温度	商业级/工业级/军品级可选

F-tone型号	QSFP28-50G-LR	制造商名称	F-tone
封装	QSFP28	传输速率	50Gbps
波长	1310nm	最远传输距离	10km
接口类型	双工 LC	发射激光器类型	DML
线缆类型	单模(SMF)	光接收器件类型	PIN
发射光功率	-4.5~+4.2dBm	接收灵敏度	< -8.4dBm
协议	MSA Compliant, SFF-8665 and SFF-8679	工作温度	商业级/工业级/军品级可选

 Supports 50GBASE-LR

 Lane signaling rate 26.5625 Gb/s with PAM4

 Up to 10km transmission on SMF

 DML TOSA and PIN ROSA

 High-speed I/O electrical interface

 QSFP28 MSA package with duplex LC connector

 Single +3.3V power supply

 Support Huawei TX_DIS and RX_LOS for telecom applications

 Maximum power consumption 3.5 W

 Compliant with IEEE 802.3cd, SFF-8636 and SFF-8679, EU Directive 2015/863/EU

50G QSFP28 LR Transceiver Module (1310nm SMF 10km LC DDM)

The 50G QSFP28 LR transceiver module is designed for 50G Ethernet links over 10Km single-mode fiber. Built-in Digital Diagnostic Monitoring (DDM) allows access to real-time operating parameters via the I2C interface. It is QSFP28 MSA, SFF-8636, and SFF-8679 compliant and suitable for 50GBASE Ethernet, 5G network mid/backhaul applications.

Quality Assurance

Excellent quality is the foundation of F-tone’ s survival and development. Our operation team are experts with many years’ experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

: Keep In Stock; Fast Delivery

: Professional Service; Technical Support

: Worry-Free Guarantee; Shopping Satisfactorily

: Premium Quality; High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.F-tone adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

: Temperature Impact; High and low temperature cycle,aging test to ensure good temperature characteristics

: Mechanical Impact; Mechanicalvibration testing to ensure the stability of products

: EMI Testing; Excellent designand rigorous testing ensuregood EMI performance

: MTBF Testing; MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

F-tone Compatibility Testing Center has most of the mainstream brand switches and devices.Before
shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

: Coding(EEPROM Programming)

: Testing system

本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！

Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
