工作温度：商业级/工业级/军品级可选
产品特点
- 具有SC/PC接口的单纤双向SFP
- 1490nm连续模式2.5Gbps DFB发射器
- 1310nm突发模式1.25Gbps APD-TIA接收器
- 传输距离20KM以上
- 支持DDM，可提供针对电源、温度、发射和接收状态、使用寿命终结等诊断和监测功能
产品标准
- 符合SFP MSA，符合SFF-8472，符合ITU-T G.984.2，符合ITU-T G.984.5，符合RoHS
技术参数
| 规格 | 封装 | 型号 | 速率 | 波长 | 激光器 | 接口 | 发射光功率 | 是否带DDM |
| GPON OLT class B+ |
SFP | FT-L1-DGT2-4924-2CY2 | 2.5Gbps/1.25Gbps | Tx1490Rx1310 | DFB/APD | SC | 2~5dbm | 是 |
| GPON OLT class C+ |
SFP | FT-L1-DGT2-4924-2CY2 | 2.5Gbps/1.25Gbps | Tx1490Rx1310 | DFB/APD | SC | 3~5dbm | 是 |
| GPON OLT class C++ |
SFP | FT-L1-DGT2-4924-2CY2 | 2.5Gbps/1.25Gbps | Tx1490Rx1310 | DFB/APD | SC | 5~7dbm | 是 |
| GPON OLT class C+++ |
SFP | FT-L1-DGT2-4924-2CY2 | 2.5Gbps/1.25Gbps | Tx1490Rx1310 | DFB/APD | SC | >7dbm | 是 |
本产品为 北亿纤通 | F-tone Networks FT-L1系列产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. rther details are available from any Andxe System sales representative.
