北亿纤通拥有SFP 3G BIDI DUAL MM以及CWDM和DWDM系列全距离单纤双向光模块，具有低功耗，高可靠性等优点，满足商业级、拓展级和工业级工作温度，其耐高温特性和抗干扰能力达到业界一流，兼容MSA, SFF-8472, SFF-8431等标准，广泛应用于数据中心、城域网、无线网络、传输网络等。
工作温度：商业级/工业级/军品级可选
产品特点
- 最大速率高达3.125Gbps，采用可热插拔的SFP封装
- 850nm/1310nm/1550nm DFB激光器和PIN光源探测器
- 或1490nm/1550nm DFB激光器以及PIN光源探测器
- 通过单模光纤传输距离可达100KM
- 支持DDM，可提供针对电源、温度、发射和接收状态、使用寿命终结等诊断和监测功能
产品标准
- 符合SFP MSA，符合SFF-8472，符合ITU-T G.984.2，符合ITU-T G.984.5，符合RoHS
技术参数
| 封装 | 型号 | 速率 | 距离 | 波长 | 激光器 | 接口 | 工作温度 | 是否带DDM |
| SFP 3G BIDI | ||||||||
| SFP | FT-L1-DFP2-313G-2CY1 FT-L1-DFP2-553G-2CY1 |
3.125Gbps | 20KM | Tx1310 Rx1550 |
DFB/PIN | LC/SC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-DFP2-313G-4CY1 FT-L1-DFP2-553G-4CY1 |
3.125Gbps | 40KM | Tx1310 Rx1550 |
DFB/PIN | LC/SC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-DFP2-453G-6CY1 FT-L1-DFP2-543G-6CY1 |
3.125Gbps | 60KM | Tx1490 Rx1550 |
DFB/PIN | LC/SC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-DFP2-453G-8CY1 FT-L1-DFP2-543G-8CY1 |
3.125Gbps | 80KM | Tx1490 Rx1550 |
DFB/PIN | LC/SC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-DFP2-453G-ACY1 FT-L1-DFP2-543G-ACY1 |
3.125Gbps | 100KM | Tx1490 Rx1550 |
DFB/PIN | LC/SC | 0~70℃ -40~85℃ |
是 |
| SFP 3G DUAL | ||||||||
| SFP | FT-L1-SFP1-313G-2CY1 | 3.125Gbps | 20KM | 1310 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-SFP1-313G-4CY1 | 3.125Gbps | 40KM | 1310 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-SFP1-553G-6CY1 | 3.125Gbps | 60KM | 1550 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-SFP1-553G-8CY1 | 3.125Gbps | 80KM | 1550 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
| SFP | FT-L1-SFP1-553G-ACY1 | 3.125Gbps | 100KM | 1550 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
| SFP 3G DUAL MM | ||||||||
| SFP | FT-L1-SFP1-8M3G-SCY1 | 3.125Gbps | 550M | 850 | DFB/PIN | 双LC | 0~70℃ -40~85℃ |
是 |
本产品为 北亿纤通 | F-tone Networks FT-L1系列产品线，详细信息，请联系我们的销售人员，谢谢！
