产品特点
- 它可以拉伸数倍而不损害光学特性。
- 可调节电缆长度
- 它足够耐用，可用于机器的可移动部件以及用作仪器的连接线。
- 电信、远程 ONU 和 FTTX。
- 数据通信、CATV 和测试设备。
- 快速部署的局域网。
- 快速管内接线。
- 机械臂传感器通信
卷曲光纤跳线可伸缩，可用于家庭布线和机器活动部件布线。卷曲长度（cm）和总长度可根据客户要求在Fiber-Mart定制。 米是指拉直后电缆的长度。 弯曲直径、弯曲圈数可根据您所需的总长度定制。
According to the customer’s requirements
According to the customer’s requirements
<1dB for 100 turns
UPC>=50,APC>=60
Operating Temperature(℃)
Storage Temperature(℃)
RoHs 2002/95/EC directive
F-tone是卷曲纤维贴片的专业制造商和供应商，可以定制任何长度。 如果您对此有任何疑问，请随时联系我们：sales@F-tone.cn
|
Cable OD(mm) |
2 or 3 |
|
Curl OD(mm) |
18-22 |
|
Curl Length(cm) |
According to the customer’s requirements |
|
Total Length(cm) |
According to the customer’s requirements |
|
Faber Type |
Bendsafe G657B |
|
Cable Material |
TPU（white） |
|
Connector Type |
ST/UPC,FC/UPC |
|
Insertion Loss(dB) |
<1dB for 100 turns |
|
Reture Loss(dB) |
UPC>=50,APC>=60 |
|
Operating Temperature(℃) |
-40℃~+80℃ |
|
Storage Temperature(℃) |
-45℃~+85℃ |
|
Fireproof standard |
IEC 60332-3 |
|
RoHs 2002/95/EC directive |
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！ Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. rther details are available from any Andxe System sales representative.
