100G QSFP28 ZR4 optical transceiver module, support 100Gb/s and up to 80 km transmission on SM fiber, it works in high-speed IDC connection solutions, and so on.
Features
- 4 lanes MUX/DEMUX design
- Support 100GBASE-ZR4 for line rate of 103.125Gbps and OTU4 for line rate of 111.81GbpsLANWDM EML laser and PIN receiver with SOA
- Aggregate bandwidth of >100Gbps
- Duplex LC connectors
- Compliant withIEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUI-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard·
- Single +3.3V power supply operating
- Built-in digital diagnostic functions
- Temperature range 0°C to 70°C
- RoHS Compliant Part
- Support FEC(Forward Error Correction)
100G ZR4 80km QSFP28 Transceiver Hot Pluggable, Duplex LC Connector, EML+PIN with SOA Single mode DDM
F-tone’s QSFP28 100G ZR4 FQ-100G-ZR4 is designed for 80km optical communication applications. This module contains 4-lane optical transmitter, 4-lane optical receiver and module management block including 2 wire serial inter-face. The optical signals are multiplexed to a single-mode fiber through an industry standard LC connector. A block diagram is shown in Figure 1.
Absolute Maximum Ratings
|
Parameter |
Symbol |
Min. |
Typical |
Max. |
Unit |
|
StorageTemperature |
TS |
-40 |
|
+85 |
°C |
|
SupplyVoltage |
VCCT, R |
-0.5 |
|
4 |
V |
|
RelativeHumidity |
FH |
0 |
|
85 |
% |
工作温度：商业级/工业级/军品级可选
本产品为 北亿纤通 | F-tone Networks FT-81系列产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
