100Gb QSFP28 ER4 40Km 1310nm LC Optical Transceiver

100Gb QSFP28 ER4 40Km 1310nm LC Optical Transceiver

100G QSFP28 ER4 optical transceiver module, support 100Gb/s and up to 40 km transmission on SM fiber, it works in high-speed IDC connection solutions, and so on.

Features:

  • 4 lanes MUX/DEMUX design
  • Support 100GBASE-ER4 for line rate of 103.125Gbps.
  • Integrated LAN WDM TOSA / FOSA for up to 40 km reach over SMF.
  • Aggregate bandwidth of >100Gbps
  • Duplex LC connectors
  • Compliant withIEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUI-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard·
  • Single +3.3V power supply operating
  • Built-in digital diagnostic functions
  • Temperature range 0°C to 70°C
  • RoHS Compliant Part
  • Support FEC(Forward Error Correction)

100G ER4 40km QSFP28 Transceiver Hot Pluggable, Duplex LC Connector, EML+APD SingleMode DDM

The 100G ER4 40KM FQ-100G-ER4 is a transceiver module designed for 40km optical communication applications. The design is compliant to 100GbASE-ER4 of the IEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUI-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard. The module converts 4 inputs channels (ch) of 25.78 Gbps electrical data to 4 lanes optical signals, and multiplexes them into a single channel for 100Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 100Gb/s input into 4 lanes signals, and converts them to 4 lanes output electrical data.

Absolute Maximum Ratings

Parameter

Symbol

Min.

Typical

Max.

Unit

Storage Temperature

TS

-40

+85

°C

Supply Voltage

VCCT, R

-0.5

4

V

Relative Humidity

FH

0

85

%

工作温度：商业级/工业级/军品级可选

本产品为 北亿纤通 | F-tone Networks FT-81系列产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
