Features

1550nm or DWDM EML Laser with TEC,Available in all C‐Band Wavelengths on the 50GHz
PIN- TIAReceiver
LC duplex connector or customizable pigtail fiber
Single Channel+ 3.3V Power Supply
The CDR off-line mode supports 155-9.95 GBIT/s bit rate, and the CDR mode supports 9.95-10.3125 GBIT/s bit rate
Internal Transmitting/Receiving CDR
-40℃ to 85℃ Working Industria Temperature
Suitable for40km SMF connection
Comply with SFF-8472 Rev 10.2
Whole Metal Shell and Excellent electromagnetic interference performance
Completely comply with RoHS Standard

FSFD-10GD-CXX Series

155M~10Gb/s 40km DWDM SFF Transceiver Module, Duplex LC, +3.3V,50GHz, DWDM EML, Single mode

F-tone’s FSFD-10GD40-Cxx is a surface mounted transceiver module, it supports 155-9.95 GBIT/s bit rate in the CDR off-line mode, and9.95-10.3125 GBIT/s bit rate in CDR mode.Suitable for40km SMF connection, and-40℃to 85℃ Working Industrial Temperature, it grate used in DWDM transfer mission system.

Diagrammatic Layout

Product Information

Type	Bite Rate	Wavelength of Laser(nm)	Transmission Range(km)	Fiber Type	Connector	Temperature
1550	155M-10.3125G	1550	40	SMF	LC	-40~+85℃
DWDM	155M-10.3125G	50Ghz DWDM	40	SMF	LC	-40~+85℃

工作温度：商业级/工业级/军品级可选

本产品为北亿纤通 | F-tone Networks FT-81系列产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
