北亿纤通拥有1X9 1.25G BIDI、DUAL、MM系列全距离光模块，具有低功耗，高可靠性等优点，满足商业级、拓展级和工业级工作温度，其耐高温特性和抗干扰能力达到业界一流，符合RoHS,FDA，广泛应用于以太网传输、SDH、光纤收发器和视频光端机等设备。
工作温度：商业级/工业级/军品级可选
产品特点
- 最大速率高达1.25Gbps
- 1310nm/1550nm FP/DFB激光器和PIN/APD光源探测器
- 或1490nm/1550nm DFB激光器以及PIN/APD光源探测器
- 通过单模光纤传输距离可达120KM
- 支持SC/FC/ST接口可选
产品标准
- 符合RoHS,FDA
技术参数
| 封装 | 型号 | 速率 | 距离 | 波长 | 激光器 | 接口 | 工作温度 | 是否带插芯 |
| 1X9 1.25G BIDI | ||||||||
| 1X9 | FT-L1-DYJ2-3024-2C82 FT-L1-DYJ2-5524-2C82 |
1.25Gbps | 20KM | Tx1310 Rx1550 |
FP/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ2-3124-4C82 FT-L1-DYJ2-5524-4C82 |
1.25Gbps | 40KM | Tx1310 Rx1550 |
DFB/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ2-4524-6C82 FT-L1-DYJ2-5424-6C82 |
1.25Gbps | 60KM | Tx1490 Rx1550 |
DFB/APD | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ2-4524-8C82 FT-L1-DYJ2-5424-8C82 |
1.25Gbps | 80KM | Tx1490 Rx1550 |
DFB/APD | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ2-4524-AC82 FT-L1-DYJ2-5424-AC82 |
1.25Gbps | 100KM | Tx1490 Rx1550 |
DFB/APD | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ2-4524-CC82 FT-L1-DYJ2-5424-CC82 |
1.25Gbps | 120KM | Tx1490 Rx1550 |
DFB/APD | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 1.25G DUAL | ||||||||
| 1X9 | FT-L1-DYJ1-3024-2C82 | 1.25Gbps | 20KM | 1310 | FP/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ1-3124-4C82 | 1.25Gbps | 40KM | 1310 | DFB/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ1-5524-6C82 | 1.25Gbps | 60KM | 1550 | DFB/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ1-5524-8C82 | 1.25Gbps | 80KM | 1550 | DFB/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ1-5524-AC82 | 1.25Gbps | 100KM | 1550 | DFB/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 | FT-L1-DYJ1-5524-CC82 | 1.25Gbps | 120KM | 1550 | DFB/APD | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
| 1X9 1.25G DUAL MM | ||||||||
| 1X9 | FT-L1-DYJ1-3M24-SC82 | 1.25Gbps | 550M | 1310 | FP/PIN | SC/FC/ST | 0~70℃ -40~85℃ |
是 |
本产品为 北亿纤通 | F-tone Networks FT-L1系列产品线，详细信息，请联系我们的销售人员，谢谢！
