工业级100Gbps LWDM ZR4 LC双纤双向QSFP28光模块

工业级100Gbps LWDM ZR4 LC双纤双向QSFP28光模块

产品概述：

成都北亿纤通科技生产的 100G QSFP28 ZR4 80KM4波长LAN-WDM的光模块为客户提供100千兆以太网连接选项，并通过单模光纤(SMF)连接高达80KM的传输距离。FTACQQ7-HHLZC*是一个100Gb/s的光收发模块，适用于光通信应用，符合QSFP28MSA,100GBASE-ZR4,CAUI-4要求。为了提供103.1Gbps的聚合信号速率，收发器以4个25.78Gbps的并行数据流运行。LWDM通道的中心波长分别为1295.56、1300.05、1304.58和1309.14nm，作为LWDM波长网格的成员，复用到单模光纤上。在接收端，光数据流的四个通道被收发器解复用并重新定时。典型的应用是互联网服务提供商(ISP)光纤到家庭聚合和骨干网、移动运营商核心网和移动回程和数据中心的站点互连。

产品特性：

在主KR4FEC的单模光纤上传输可达80公里

支持103.125Gbps的聚合比特率

热插拔38pin电接口

QSFP28MSA兼容

4个LWDM波长1295.56、1300.05、1304.58和1309.14nm

冷却LAN-WDMEMLTOSASOA+销接收机

CAUI-4兼容功耗<6.5W

工作箱温度:-40~85°C

行业标准LC双工连接器

单路3.3V电源

IEC60825-11级/CDRH1级激光眼睛安全

本产品为 北亿纤通 | F-tone Networks 产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
