产品概述
FT-PLC-16×16是北亿纤通（F-tone Networks）16×16 PLC平面光波导分路器，采用二氧化硅光波导技术，具有体积小、可靠性高、工作波长范围宽、通道均匀性好的特点，广泛用于PON网络实现光信号功率分配。
工作温度：商业级/工业级/军品级可选
产品特性
- 低插入损耗
- 低偏振相关损耗
- 高可靠性与稳定性
- 符合GR-1221和GR-1209标准
- 符合RoHS标准
- 19英寸1U机架封装可选
应用场景
- FTTH光纤到户
- 无源光网络PON
- 移动/电信网络
- LAN/MAN
- CATV链路
技术规格
| 参数 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 工作波长 | – | 1260 | – | 1650 | nm |
| 插入损耗 | – | – | – | 28 | dB |
| 损耗均匀性 | – | – | – | 3.6 | dB |
| 偏振相关损耗 | PDL | – | – | 0.5 | dB |
| 回波损耗 | – | 50 | – | – | dB |
| 方向性 | – | 50 | – | – | dB |
| 温度稳定性 | – | – | – | 0.5 | dB |
| 最大承受功率 | – | – | – | 500 | mW |
| 工作温度 | – | -10 | – | +70 | °C |
| 封装尺寸 | – | 482.6×200×44 | – | – | mm |
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
