产品概述
FT-4X4-SM是北亿纤通（F-tone Networks）4×4机械光开关，工作波长1260～1650nm，具有宽波段、低串扰、高稳定性的特点，光路无环氧胶，支持TTL电平通道选择与状态回读，适用于实验室研发与系统监控。
工作温度：商业级/工业级/军品级可选
产品特性
- 宽工作波长范围1260～1650nm
- 低串扰≥55dB
- 高稳定性、高可靠性
- 光路无环氧胶
- TTL通道选择与状态输出
- 切换时间≤8ms
应用场景
- 实验室研发
- 系统监控
- OADM
- OXC光交叉连接
技术规格
| 参数 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 工作波长 | – | 1260 | – | 1650 | nm |
| 插入损耗 | – | – | – | 2.5 | dB |
| 回波损耗 | – | 50 | – | – | dB |
| 串扰 | – | 55 | – | – | dB |
| 偏振相关损耗 | PDL | – | – | 0.15 | dB |
| 波长相关损耗 | WDL | – | – | 0.35 | dB |
| 切换时间 | – | – | – | 8 | ms |
| 耐久性 | – | – | ≥1000万 | – | 次 |
| 光功率 | – | – | – | 500 | mW |
| 工作温度 | – | -5 | – | +70 | °C |
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
