产品概述
FT-79-LA-C1821NA-U000是一款高速驱动放大模块，针对脉冲信号特殊设计，带宽覆盖1kHz~6GHz，脉冲高保真度，可作为调制器驱动或射频放大器使用。
工作温度：商业级/工业级/军品级可选
产品特性
- 超宽模拟工作频率1kHz~6GHz
- 典型增益21dB，增益波动≤±1.5dB
- 典型上升沿60ps，脉冲高保真度
- 上升沿RMS抖动典型值≤2ps
- 50Ω SMA射频输入输出接口
- 出色的EMC/EMI设计，针对脉冲信号优化
应用场景
- 调制器驱动
- 射频放大
- 测试测量
- 快速同步系统
- 脉冲发生器
技术规格
| 参数 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 工作频率范围 | – | 1k | – | 6G | Hz |
| 增益 | – | 21 | – | 24 | dB |
| 增益波动 | – | – | – | ±1.5 | dB |
| 上升/下降沿时间 | – | – | 60 | 70 | ps |
| 抖动 | – | – | 2 | 3 | ps RMS |
| 输出脉冲幅度 | – | – | 4.5 | 5 | Vpp |
| 输入输出回波损耗 | – | – | -10 | – | dB |
| 射频输出阻抗 | – | – | 50 | – | Ω |
| 工作电压 | – | 14.7 | 15 | 15.5 | V |
| 功耗 | – | – | 2.1 | 2.8 | W |
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
