产品概述
FT-SOA-XX系列是北亿纤通（F-tone Networks）专为100G光通信系统设计的半导体光放大器，核心器件采用高性能SOA，独特的APC和ATC电路使输出功率稳定度高、可靠性好，提供纯光模块、带电模块、台式与机架等多种结构。
工作温度：商业级/工业级/军品级可选
产品特性
- 高饱和输出功率，低噪声系数
- 高稳定性和高可靠性
- 高精度AGC/APC与ATC电路
- 灵活的机械与电路结构
- 符合Telcordia GR-1312-CORE
应用场景
- 100G光通信系统
- 光信号放大中继
- 城域/骨干传输
技术规格
| 参数 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 工作波长 | λc | – | 1310 | – | nm |
| 输出光功率 | Po | 2 | 6 | 10 | dBm |
| 输入光功率 | Pi | -16 | – | -8 | dBm |
| 光增益 | Gain | – | 18 | – | dB |
| 增益平坦度 | ΔG | – | – | 2 | dB |
| 噪声系数 | NF | – | – | 8 | dB |
| 输入输出隔离度 | ISO | 30 | – | – | dB |
| 偏振相关增益 | PDG | – | 0.5 | – | dB |
| 工作温度 | Top | -5 | – | 60 | °C |
| 存储温度 | Ts | -40 | – | 85 | °C |
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. rther details are available from any F-tone Networks sales representative.
