400G CFP2 DCO Optical Transceiver Module | F-tone 北亿纤通

400G CFP2 optical transceiver module
Used on the system’s motherboard
Up to2000 km in MAN DWDM application

100G/200G/400G CFP2 DCO Pluggable Optical Transceiver Module

Product Features

100G CFP2-DCO coherent optical module operating up to 112.30 Gbps
200G CFP2-DCO coherent optical module operating up to 211.45 Gbps
400G CFP2-DCO coherent optical module operating up to 425 Gbps
PM-QPSK (100G/200G) and PM-16QAM (200G / 400G) and PM-16QAM PS (200G) modulation formats
CFP2 MSA Hardware Specification 1.0 with modifications compliant
CFP MSA Management Interface Specification 2.2 with modifications compliant
Maximum power consumption: 31 W

Optical Port Specifications

DCO-200G-C

Parameter	100GModeValue	200GModeValue
Network lane, modulation format	PM-QPSK	PM-16QAM
Optical channels	96	96
Grid spacing	50 GHz	50 GHz
Frequency range	191.3 to 196.05 THz	191.3 to 196.05 THz
Wavelength stability	±1.5 GHz	±1.5 GHz
Tx output power, default	-0.5 dBm	-0.5 dBm
Max. Tx output power	-0.5 dBm	-0.5 dBm
Min. Tx output power	-6.5 dBm	-6.5 dBm
Tx output power accuracy	±1.5 dBm	±1.5 dBm
Output power during tuning	< -35 dBm	< -35 dBm
CD tolerance	±40 000 ps/nm	±10 000 ps/nm
DGD tolerance	50 ps	12 ps
Input power range	0 to -18 dBm	0 to -18 dBm
OSNR tolerance (BOL)	12.5 dB (Rx optical power: -8 to -10 dBm)	23 dB (Rx optical power: -8 to -10 dBm)
Power consumption	Typical: 24 W Maximum: 27.5 W	Typical: 27.5 W Maximum: 31 W

工作温度：商业级/工业级/军品级可选

本产品为北亿纤通 | F-tone Networks FT-81系列产品线，详细信息，请联系我们的销售人员，谢谢！Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by Andxe System before they become applicable to any particular order or contract. In accordance with the Andxe System policy of continuous improvement specifications may change without notice.The publication of information in this data sheet does not imply freedom from patent or other protective rights of Andxe System or others. Further details are available from any Andxe System sales representative.
