产品概述
FT-88-M440A 是单通道常开型固态继电器，输入侧为 AlGaAs 红外 LED，输出侧为光伏二极管阵列加 MOSFET。负载电压 400V，连续负载电流 120mA，导通电阻典型值仅 20Ω，适用于交换设备、工业控制与安防系统。
工作温度：商业级/工业级/军品级可选
产品特性
- 负载击穿电压 400V，连续负载电流 120mA
- 导通电阻低，典型值 20Ω
- 输入输出绝缘电压 3750Vrms
- 1 Form A 常开型，SOP-4 小封装
- 无卤素，符合 RoHS/REACH
- 通过 UL、VDE、CQC 安全认证
应用场景
- 交换设备
- 测量与测试设备
- FA/OA 设备
- 工业控制
- 安防系统
技术规格
| 参数 | 符号 | 最小值 | 典型值 | 最大值 | 单位 |
|---|---|---|---|---|---|
| 负载击穿电压 | LV | – | – | 400 | V |
| 连续负载电流 | IL | – | – | 120 | mA |
| 绝缘电压 | Viso | – | – | 3750 | Vrms |
| 导通电阻 | Rd(ON) | – | 20 | 30 | Ω |
| 正向电压 | VF | – | 1.38 | 1.81 | V |
| 关断泄漏电流 | Ileak | – | – | 1 | μA |
| 开通时间 | Ton | – | 0.25 | 1 | ms |
| 关断时间 | Toff | – | 0.05 | 0.5 | ms |
| 推荐负载电压 | VL | – | – | 320 | V |
| 封装形式 | – | – | SOP-4 | – | – |
本产品为北亿纤通产品线，详细信息，请联系我们的销售人员，谢谢！
